SAE J1772 Type 1 To IEC 62186 Type 2 AC EV Adapter For Electric Car Charging

· With built-in thermostat to avoid thermal disorder, which can protect your electric vehicle well.

· With a flocking drawstring bag for storage, which helps to prevent the dust and static. It prolong the adapter’s lifespan.

· Our adapter weighs only 380 grams, It’s super portable for your electric vehicle.

· Our adapter allows most of Type 2 electric vehicles or Type 1 sockets to charge from a Type 1 charging plug.

Item No :
WB-IEC-EV32A
Product Origin :
China
Brand :
WORKERSBEE Or Customized
Certification :
CE
Warranty :
2 Years

Inquire Now

Type 1 and Type 2 EV adapters are used for connecting electric vehicles (EVs), equipped with Type 2 charging ports, to charging stations that accept Type 1

Rated Current	32A 1 Phase
Rated Voltage	250V AC
Standard	EN62196-2 & SAEJ1772
Flame Retardant Rating	UL94 V-0
Protection Level	IP54
Insulation Resistance	0.5mΩ Max
Insertion and Withdrawal Force	＜100N
Mechanical Life	＞10000 times of plug in/ off
Working Temperature	-30℃~+50℃
Casing	Thermoplastics (PC)
Conductor	Silver-plated Copper Alloy

Cost-Efficient

This EV adapter allows EVs with different charging ports to be charged at charging stations that are compatible. EVs equipped with Type 2 ports can now charge at Type 1 stations using this adapter. This adapter is simple to use and ensures that owners of electric vehicles can charge their cars at any time.

Easy Carry

The Type 1 to Type 2 adapter, which is small and lightweight, is easy to store and carry. Transport costs are low, and traveling is convenient.

Investment Value

This type 1 to type 2 allows them to charge in the location they prefer. The adapter is a valuable tool because it allows drivers to charge at multiple locations. This adapter can be used to charge vehicles in multiple locations and on the move.

Safe Standard

All EV Adapters are rigorously tested to ensure their performance and safety. Each adapter undergoes a series testing to ensure that it meets safety standards. The protective cover on the EV Adapters is IP54-certified, which means it is protected against dust or splashes of water.

Hot Tags : ev charging adapters ev charging cable adapter type 1 ev charging cable adapter type 2 type 1 to type 2 ev adapter ev charger type 1 to type 2 adapter ev type 1 to type 2 adapter
